AK-Motion BMW 3 Series E90 E91 E92 E93 (E9x) Vent-Mounted Touchscreen OBD2/OBD II Display | Digital Dash Vent Gauge Scan Gauge Boost Gauge Performance Monitor & Code Reader | 320i 330i 335i N54 N55 Plug & Play Lap Timer

AK-Motion Vent-Mounted Digital Display for BMW E9x 3 Series 320i 330i 335i

Transform your centre air vent into a smart, factory-style gauge cluster. The AK-Motion touchscreen unit delivers live engine telemetry through your diagnostics port, giving you instant visibility of critical parameters without pods or pillar gauges. Designed for BMW E90, E91, E92 and E93, this discreet vent-mounted screen looks OEM, boots quickly and puts performance data exactly where you want it.

We have fitted these at MJ Modifications in Warwickshire and the feedback has been outstanding. Clean integration, rock-solid data, proper track-day tools and daily-driver convenience. If you want a stealth digital dash with real-time monitoring for your E9x, this is the enthusiast’s choice.

Highlights

• Purpose-built for BMW 3 Series E90 E91 E92 E93 with a neat centre-vent frame
• Capacitive touchscreen 3.2 inch full-colour display with anti-glare film and custom themes
• Create your own dashboards with up to eight values, choose numeric or bar-graph views
• Performance timers for 0-100, 100-200, 1/8, 1/4 and 1/2 mile, with run history and max-value logging
• Adjustable shift light plus optional instrument cluster flash for precise gear changes
• Reads and clears engine fault codes, with secure OBD II blocker unlock by code
• Plug-in harness, USB firmware updates and multi-language, unit and colour options

Please include your VIN at checkout so we can ensure the correct configuration for your vehicle.

Live data and functions

• Boost pressure actual and target values, with N54 scaled map compensation over 1.5 bar
• Intake air temperature, coolant temperature, oil temperature and battery voltage
• Air flow, lambda value with AFR support, ignition timing and firing angle
• Fuel system: fuel pressure and rail pressure
• Transmission temperatures for automatic and DKG on E-series and F-series where supported
• Exhaust temperature calculated, plus optional external EGT sensor support
• G-Force meter, speed with GPS match option, power and torque readouts
• DPF data for supported engines: differential pressure, soot mass, pressure before DPF and distance since last regeneration
• Customisable dashboards: up to three simultaneous bar graphs or numeric fields, plus flow diagrams for four parameters
• Brightness control: automatic and manual
• Shift light on the display with optional flash in the instrument cluster
• Control up to four relays directly from the unit
• Flap control and speedometer needle sweep on ignition
• Enable diagnostic access via the display and clear engine error codes
• Save and reset maximum values plus store the last four timing measurements
• Unit settings: language and units including English, German, Italian, French, Dutch, bar or psi, PS or kW, lambda or AFR, °C or °F
• Vehicle-specific toggles where available: Active Sound Design on certain F-series, DSC and DTC start-up behaviour on E-series, burble enable on F-series

Note: Feature availability depends on engine and platform. F-series specific options are listed for completeness. G-series is not supported.

Diesel engines and oil temperature

Some E-series diesel models can show oil temperature without an additional sensor. For most E9x diesels, an external oil temperature sender is required except for N57. Unsure what you need for your 320d or 330d setup? Get advice at info@mjmodifications.co.uk.

What you get in the box

• Control unit
• 3.2 inch full-colour display with centre-vent mounting frame
• Vehicle connection cable set
• Display cable
• USB cable for updates
• Matte anti-reflection film
• 2x socket housings for any required re-wiring

Compatibility

• BMW 3 Series E90 E91 E92 E93 across the range, including 320i, 330i and 335i

Important: LHD vehicles only. The supplied vent frame does not fit RHD cars.

Installation

Designed for a tidy centre-vent fit with a simple plug-in harness. For professional installation, book with MJ Modifications in Warwickshire. Request a fitting quote at info@mjmodifications.co.uk.

Ordering notes

• Include your VIN so we can verify vehicle specifics
• Functions vary by engine and platform

Part number

AKME9X1000

Brand

AK-Motion

Ideal for E9x owners seeking a vent-mounted digital dash, OBD II scan gauge, BMW 3 Series engine monitor, 335i boost reader, 330i telemetry display or 320i diagnostics screen that looks stock and delivers track-ready data. Trusted by our workshop and customers who want performance insights without compromising the interior.

Popular search terms: BMW E90 digital dash, BMW E92 vent gauge UK, BMW 3 Series OBD II display, BMW E9x live data screen, BMW 335i boost monitor, BMW E90 code reader, BMW E93 performance timer, BMW 320i diagnostics, BMW N54 boost gauge, BMW E9x telemetry, BMW E90 lap timer, BMW 3 Series vent-mounted screen.
