Jaguar XF/XFR 2009-2011, XK/XKR 2009-2015 Apple CarPlay & Android Auto Retrofit - Mr12Volt P2000 MM MOST Fibre Optic Interface with OEM Microphone, Wireless & Wired, DSP, Bluetooth, USB, Camera Inputs (P2000-XF09MM)

Jaguar XF XFR XK XKR smartphone integration upgrade with OEM mic and MOST fibre audio

Part number: P2000-XF09MM

Give your Jaguar cabin a modern refresh with a premium smartphone link that looks factory and sounds superb. This Mr12Volt P2000 MM unit connects over the car’s fibre optic MOST network for outstanding audio quality, now with built-in DSP tuning and support for the original microphone for crisp hands-free calls and reliable voice control. We run this kit ourselves and our customers consistently praise the seamless feel, strong wireless performance and rich sound.

Vehicle compatibility

• Jaguar XF and XFR 2009 to 2011 pre-facelift
• Jaguar XK and XKR 2009 to 2015

Note: this module replaces the factory USB socket.

Key reasons enthusiasts choose this upgrade

• Factory mic integration for clear hands-free and voice assistant use
• MOST fibre audio path for pristine, low-noise sound into the OEM system
• Wireless or cable connection for iPhone - access mapping apps, Siri, music and messages
• Wireless or cable connection for Android phones - use Google Maps, Waze, Spotify and Google Assistant
• Wireless mirroring for compatible phones
• Bluetooth calling and music streaming
• USB media playback up to 1080p video
• Camera inputs for reverse, front and side views - supports up to AHD720
• Apple Lossless music support
• 15-band DSP equaliser for precise sound tailoring
• No coding - simple source selection via Portable Audio > USB

How it operates in your Jaguar

• Select Mr12Volt through the head unit path: Portable Audio > USB
• No dealer tools or software coding required
• Audio is injected on the vehicle’s MOST fibre optic bus for the best sound quality

Installation videos

Supported multimedia and codecs

• H.264 Baseline and Main High Profile, Level 1-4.2 - 30fps at 1080p
• VC-1 Simple Main Profile low, medium and high - Advanced Profile levels 0-3 - 30fps at 1080p
• MPEG1/2/4 Simple Profile 0-6 - Main Profile low, medium, high - ASP 0-5 - 30fps at 1080p
• Real-Video 8/9/10 - 30fps at 1080p
• VP6/7/8 VP6.0/1/2, VP7 v0-3, VP8 v2 WebM - 30fps at 1080p
• DivX 3/4/5/6 - 30fps at 1080p
• H.263 Profile 0 levels 10-70 - 30fps at 720x576
• JPEG Baseline interleaved - up to 8176x8176
• Containers mkv, mp4, avi, wmv, rmvb, rm, mpg, mpeg, ts, dat, asf, flv, vob and more
• Audio MP3, WMA, AAC, AC3, DTS, OGG, FLAC, APE, AMR and more

Technical highlights

• Operating temperature -20 to +80 degrees C
• DAC resolution 18-bit
• MP3 bitrate 8 to 384 kbit
• Voltage 10 to 14.6 V DC
• Operating current 450 mA rising to 700 mA when charging a phone
• Signal to noise 95 dB
• THD 0.1%
• Frequency response 20 Hz to 20 kHz

Helpful link

How to mirror your phone to the P2000

Professional fitting and UK support

Want stress-free installation carried out by specialists who fit these every week? MJ Modifications in Warwickshire can help with expert fitting and setup. Request a quote at info@mjmodifications.co.uk.
