Mr12Volt P2000-PCM30MM Porsche PCM 3.0 Apple CarPlay & Android Auto MOST Bus Fiber Optic Interface - Wireless, OEM Microphone Support - 911 2009-2011, Boxster/Cayman 2009-2012, Cayenne 2009 - Plug & Play Retrofit

Porsche PCM3 Smartphone Integration Module by Mr12Volt

Part number: P2000-PCM30MM

Transform your factory system with the Mr12Volt P2000-PCM30MM. This premium retrofit module adds seamless iPhone and Android phone integration to Porsche vehicles equipped with PCM 3.0, delivering wire-free connectivity, crisp digital audio over the car’s MOST fibre optic network and full use of the original microphone for crystal clear voice control and calls. Select it through the TV source on the head unit for a factory-style experience. We have installed this unit extensively and our customers love the quick start, stable performance, excellent sound and OEM-like operation.

If you are searching for a Porsche smartphone interface, PCM3 retrofit module, Porsche iPhone adapter, Android phone link for Porsche, fibre optic audio integration, Porsche wireless smartphone mirroring, CarPlay kit for PCM3, Android Auto kit for PCM3, or an OEM-look upgrade that keeps the original screen and controls, this is the high quality solution to choose.

Vehicle compatibility

• Porsche with PCM 3.0 head unit
• 911 2009 to 2011
• Cayenne 2009
• Boxster and Cayman 2009 to 2012

Not suitable for vehicles with CDR31.

Important: If your car has the factory TV function already built in, please wait for a future revision. With the current version, the OEM rear camera will not operate correctly.

Key benefits

• Retains the factory microphone for hands-free calls and voice assistants
• Direct MOST fibre optic integration for clean, high fidelity sound through the original amplifier
• Wireless and wired connectivity for both Apple and Android devices
• Wireless screen mirroring for supported phones
• Bluetooth hands-free calling and high quality Bluetooth music streaming
• USB media playback for video and music with broad codec support
• Multiple camera inputs for reverse, front, left and right views, supporting aftermarket cameras up to AHD 720
• Apple Lossless audio streaming support
• 15 band DSP equaliser for fine tuning to your taste

How it operates

• Access the interface via the TV function on the PCM
• No coding required and no OEM TV tuner needed. The TV icon appears on the PCM home menu after installation
• Retains original controls and integrates cleanly for an OEM look and feel

Perfect for owners who want

• Porsche iPhone integration with navigation apps on the original display
• Android phone connectivity using the factory screen and controls
• Spotify, Apple Music and podcasts through the stock audio system
• Siri and Google Assistant via the original mic
• Digital audio over the MOST optical loop for audiophile-grade clarity
• A plug-in upgrade that keeps the cabin looking original

Base audio note

For Porsche vehicles with base audio and no fibre optic cable present in the car’s harness, please follow this video to modify the supplied FO Y-cable to a direct male-to-male cable:

Multimedia and codec support

• Video decoding: H.264 Baseline and Main High Profile Level 1 to 4.2 up to 30 fps at 1080p
• VC-1 Simple and Main Profile, Advanced Profile levels 0 to 3 up to 30 fps at 1080p
• MPEG1/2/4 Simple Profile levels 0 to 6, Main Profile low to high, ASP levels 0 to 5 up to 30 fps at 1080p
• RealVideo 8/9/10 up to 30 fps at 1080p
• VP6/7/8 including WebM up to 30 fps at 1080p
• DivX 3/4/5/6 up to 30 fps at 1080p
• H.263 Profile 0 levels 10 to 70 up to 30 fps at 720 x 576
• JPEG codec Baseline interleaved up to 8176 x 8176
• Video containers: mkv, mp4, avi, wmv, rmvb, rm, mpg, mpeg, ts, dat, asf, flv, vob and more
• Audio formats: MP3, WMA, AAC, AC3, DTS, OGG, FLAC, APE, AMR and more

Technical data

• Operating temperature: -20 to +80 degrees C
• DAC resolution: 18 bit
• MP3 bit rate: 8 to 384 kbit
• Voltage: 10 to 14.6 V DC
• Operating current: 450 mA (700 mA when charging a mobile phone)
• Signal to noise ratio: 95 dB
• Total harmonic distortion: 0.1%
• Frequency response: 20 Hz to 20 kHz

Professional installation

Prefer expert fitting for your Porsche smartphone upgrade? Book with MJ Modifications, Warwickshire. Email info@mjmodifications.co.uk for a quote.

Owner feedback

We have fitted and used the P2000-PCM30MM across multiple vehicles. Feedback is consistently positive thanks to rock solid wireless performance, superb audio through the MOST system, clear calls using the factory microphone and a user experience that feels OEM.
