Mr12Volt P2000-PCM31MM Porsche PCM 3.1 MOST Bus Apple CarPlay & Android Auto Retrofit Interface 911, Boxster, Cayman, Panamera, Macan, Cayenne (20102016) Wireless/Wired, OEM Microphone, Bluetooth, USB, Camera Inputs

Part Number: P2000-PCM31MM

Porsche PCM 3.1 Smartphone Integration Upgrade via MOST Fibre Optic - Premium Retrofit Module

Modernise your Porsche cockpit with a slick, factory-style smartphone interface for PCM 3.1. The Mr12Volt P2000-PCM31MM connects over the OEM MOST fibre optic network to deliver ultra-clean audio, fast response and native-feeling control without replacing your original screen or console. Enjoy wireless or cabled iPhone and Android connectivity, crystal-clear calls through the original cabin microphone, high quality Bluetooth streaming, USB media playback, phone mirroring and multiple camera inputs - all while preserving the stock look of your dash.

We run this kit in our own cars and our customers love it. It is the enthusiast’s choice for PCM3.1, giving you modern navigation, music, messaging and voice control in a way that feels like it came from the factory. The sound quality is outstanding, integration is tidy and the driving experience is transformed.

Compatible Porsche Models - PCM 3.1 head unit

• 911 2012-2016 (991)
• Boxster 2013-2016 (981)
• Cayman 2013-2016 (981)
• Panamera 2010-2016 (970)
• Cayenne 2010-2016 (958)
• Macan 2014-2016 (95B)

Why enthusiasts choose this retrofit

• OEM microphone integration - use your factory mic for authentic voice clarity and reliable voice commands
• MOST Bus connection - taps into the fibre optic audio path for proper OEM-like behaviour and superb sound
• Wireless or wired Apple CarPlay and Android Auto - fast pairing, stable performance, no clutter
• Wireless MirrorLink - handy for screen mirroring your phone
• Bluetooth hands-free and A2DP streaming - easy calls and high quality music
• USB media support - play video and audio files direct from a drive
• Multiple camera inputs - reverse, front, left and right supported, with aftermarket cameras up to AHD720
• Apple Lossless support - enjoy high fidelity audio
• 15-bar DSP equaliser - dial in your sound to taste

Simple operation - feels factory

• Access the interface by selecting the TV source on PCM
• No coding required and no factory TV module needed - the TV icon appears on the home menu once fitted
• Retains the OEM look and user experience of PCM 3.1

Important notes

• If your car already has OEM TV, hold off purchasing for now - the factory reverse camera will not function correctly with this version
• Base audio vehicles without a fibre optic cable in the harness - follow the video guide below to adapt the supplied FO Y-cable to a direct male to male FO lead

Supported media formats via USB

• Video codecs: H.264 Baseline/Main/High Profile Level 1-4.2 up to 30 fps at 1080p, VC-1 Simple/Main/Advanced levels 0-3 up to 30 fps at 1080p, MPEG-1/2/4 Simple and Main Profiles, ASP levels 0-5 up to 30 fps at 1080p, RealVideo 8/9/10 up to 30 fps at 1080p, VP6/7/8 including WebM up to 30 fps at 1080p, DivX 3/4/5/6 up to 30 fps at 1080p, H.263 Profile 0 levels 10-70 up to 30 fps at 720x576
• Image: JPEG Baseline interleaved up to 8176x8176
• Container formats: mkv, mp4, avi, wmv, rmvb, rm, mpg, mpeg, ts, dat, asf, flv, vob and more
• Audio: MP3, WMA, AAC, AC3, DTS, OGG, FLAC, APE, AMR and more

Technical data

• Operating temperature: -20 to +80 °C
• DAC resolution: 18-bit
• MP3 bit rate: 8-384 kbit
• Voltage: 10-14.6 V DC
• Operating current: 450 mA (700 mA when charging a mobile phone)
• S N ratio: 95 dB
• Total harmonic distortion: 0.1 percent
• Frequency response: 20 Hz-20 kHz

Professional fitting and support

For a neat, hidden install and the best results on PCM 3.1, book professional fitting with MJ Modifications in Warwickshire. Request a quote at info@mjmodifications.co.uk.
