SPL Parts BMW F2X/F3X xDrive Front Tension Rods Adjustable Caster/Thrust Arms for 2/3/4 Series | Billet 2024 Aluminium, FK PTFE Spherical, Titanium Hardware (Pair)

BMW F2X F3X xDrive Adjustable Radius Arms for 2 Series, 3 Series, 4 Series AWD

Transform front end precision with these adjustable radius arms that replace the soft OE rubber-bushed links on BMW F2X F3X xDrive platforms. Achieve sharper response, improved stability under hard braking and repeatable alignment settings for fast road and track day use. A direct bolt-on upgrade for enthusiasts who want crisp steering feel and reliable geometry control on AWD 2 Series, 3 Series and 4 Series models.

Why upgrade

• Dial-in caster for true-and-stable tracking and to correct side-to-side variation
• Quicker turn-in with reduced compliance and a more connected front axle
• Greater confidence on the brakes thanks to tunable anti-dive using supplied stainless spacers
• Lower unsprung mass for better suspension response and grip consistency
• On-car fine adjustment for fast, precise alignment changes

Engineering details

CNC machined 2024 aluminium main links are gun drilled and black anodised to cut weight while maintaining exceptional stiffness. A 6061-T6 rotating clamp lets you set and lock geometry accurately without repeated removal. Titanium socket head hardware is blue anodised for strength with minimal mass. High-misalignment FK Bearings JMX spherical rod ends feature a PTFE liner for quiet operation, low friction and long service life in demanding environments. Hardware includes ASTM A574 cap bolts with a minimum tensile strength of 170,000 psi, plus stainless spacers to tailor anti-dive characteristics.

What you will feel

• Cleaner feedback through the wheel and a more planted front end
• More predictable mid-corner behaviour and reduced tramlining
• Improved braking stability from geometry that stays where you set it

We have installed these arms on our own builds and for customers, and the feedback is consistently excellent: sharper steering, better stability and alignment settings that hold true.

Fitment

BMW 2 Series F2X, 3 Series and 4 Series F3X chassis with xDrive all wheel drive.

Important: xDrive only. Not for rear wheel drive vehicles.

Installation and alignment

Professional fitting and a full alignment are strongly recommended after any geometry change. For expert installation and setup, contact MJ Modifications in Warwickshire for a quote at info@mjmodifications.co.uk.

Setup tip: choose an initial caster target to suit your wheel and tyre package, then fine tune with the rotating clamp and supplied spacers to balance turn-in bite and braking stability.

Part number

SPL TR F3iX

Key features at a glance

• Adjustable caster links for BMW F2X F3X xDrive platforms
• Billet 2024 aluminium links that are gun drilled and black anodised
• 6061-T6 rotating clamp for quick on-car adjustment
• FK Bearings JMX 3-piece PTFE-lined spherical joints
• Blue anodised titanium socket head hardware
• Stainless spacers to tune anti-dive
• ASTM A574 bolts rated to 170,000 psi minimum tensile strength
• Made in the USA
• Sold as a pair
