Wagner Tuning BMW N54 EVO2 Competition Front Mount Intercooler & 70mm Catless Downpipes Kit for BMW 1M, 135i, 335i/335xi (E82 E88 E90 E91 E92 E93) - SS304 High-Flow Upgrade Package

Wagner EVO2 Charge Cooler and 70 mm De‑Cat Pipe Bundle for E82 E88 E90 E91 E92 E93 N54

Transform your E‑series 3.0 twin turbo with Wagner’s EVO2 Competition charge-air cooler and straight-through 70 mm stainless de‑cat pipes. This high-flow bundle is a proven way to cut intake air temperatures, minimise restriction, improve turbo response and keep power repeatable on spirited road drives and track sessions. Perfect for E82 1M, E82 E88 135i and E90 E91 E92 E93 335i and 335xi running the N54 engine.

We run this hardware on customer cars and the feedback is consistently excellent. Fitment is tidy, pressure drop is markedly reduced and heat soak is kept in check, giving that strong, repeatable pull you want from an N54. If you’re chasing reliability with your performance, this is a go-to setup.

Why this package works

• Stepped Competition core for outstanding charge cooling and airflow efficiency
• Up to 85 percent larger frontal area and 90 percent more internal volume than factory cooler
• Noticeably lower restriction compared with the OE unit for quicker spool and stronger midrange
• True 70 mm 1.4301 SS304 de‑cat downpipes to cut backpressure and let the turbos breathe
• CAD-optimised cast aluminium end tanks for smooth, stable flow across the entire core
• Durable anti-corrosion coating that also aids heat dissipation
• Direct replacement with OE-style connections for straightforward installation

Intercooler specification - Part No. 200001044

• Core size 520 mm x 210 mm x 150 mm stepped - 13,572 cm³ volume
• Up to 85 percent larger frontal area and 90 percent more volume vs stock
• WAGNERTUNING Competition Core for high cooling capacity with low weight
• Cast aluminium end tanks developed by CAD for maximum internal flow
• Significantly reduced pressure drop compared to the factory cooler
• Approximate weight 7.4 kg
• Anti-corrosion protective coating with excellent thermal characteristics
• Direct-fit replacement supplied ready to install
• Each unit is subject to stringent quality control

Downpipe kit specification - Part No. 500001002

• True 70 mm pipework
• Manufactured from 1.4301 SS304 stainless steel
• No catalytic converters - for track and test use
• OE-style connections for a 1:1 swap with the original parts
• CAD-designed geometry with optimised flow
• Integrated flex section

Note: ECU calibration will be required to prevent engine management light warnings.

Recommended ancillary parts for downpipe installation

• 2x Genuine BMW N54 N55 N63 S63 V-band exhaust clamp - suitable for 1M, M2, 335i, Z4 35is and others
• 2x Genuine BMW N13 N54 N55 S55 turbo-side downpipe gasket - suitable for 1M, M2 Competition, M3, M4, M135i, 135i, 335i, Hybrid 3 and others
• 1x Genuine BMW N54 N55 E60 E88 E90 downpipe gasket kit - suitable for 1M, 135i, 335i, 535xi and others

What’s in the box

• Wagner EVO2 Competition Charge-Air Cooler for E82-E93 N54
• Wagner N54 70 mm SS304 de‑cat downpipes for E82-E93

Vehicle compatibility

• BMW 135i E82 and E88
• BMW 1M E82
• BMW 335i and 335xi E90, E91, E92 and E93

Note: Minor trimming or adaptation may be required to fit the EVO2 core on some listed vehicles.

Part numbers

• Package - 700001009
• Intercooler - 200001044
• Downpipe kit - 500001002

Fitting and support

Professional installation recommended. We offer supply and fitting at MJ Modifications in Warwickshire. For a quote, email info@mjmodifications.co.uk.

Manufacturer and warranty

Made by Wagner and supplied with a 2 year manufacturer warranty.
