Wagner Tuning EVO3 Competition Stepped FMIC Charge Air Cooler Kit BMW N55 F20 F21 F22 F87 M135i M235i M2 1 Series 2 Series Front Mount Intercooler Upgrade + 76mm Charge

EVO3 Competition Charge Air Cooler Kit for BMW F-Series N55 – Part No. 200001144

Unlock dependable, repeatable performance from your turbocharged straight-six with this oversized charge air cooling upgrade by Wagner Tuning. Built for BMW F20 F21 F22 and F87 models running the N55 engine platform, it delivers colder, denser air under sustained load for stronger acceleration, improved resilience against heat soak and rock-steady power on spirited road drives and track days.

We have fitted this kit on multiple customer cars at MJ Modifications and the feedback has been outstanding. Expect noticeably lower intake temps, quicker recovery between pulls and consistent performance for remapped setups, hybrid turbos and fast-road builds.

Why this upgrade stands out

• Huge step up in cooling area and core volume – frontal area up 165 percent and core volume up 223 percent compared to factory
• Competition-grade tube and fin core with internal turbulators for rapid heat transfer and fast temperature recovery
• CFD-optimised cast aluminium end tanks that remove restrictive OE bottlenecks, improving flow and reducing pressure drop
• High-flow connections with 65 mm inlet and 76 mm outlet, replacing the fragile factory click-fit joints
• Includes reinforced silicone boost hoses and a 76 mm aluminium charge pipe for a complete, high-flow solution
• Durable black anti-corrosion coating with excellent thermal dissipation
• Despite the size, the complete assembly weighs just 13.8 kg

Technical specification

• Stepped core dimensions: 510 mm x 345 mm x 180 mm
• Core volume: 23.56 litres
• Competition tube and fin construction with internal turbulators
• Cast aluminium end tanks, CFD refined
• Inlet 65 mm, outlet 76 mm
• External air shroud and revised cross member included
• Significantly lower pressure drop than the OE unit

What you receive

• Black-finished charge air cooler assembly
• 76 mm aluminium charge pipe
• External air shroud
• Pair of reinforced silicone hoses
• Aluminium adapter
• Adjusted cross member
• All required mounting hardware
• Installation guide

Vehicle compatibility

For BMW models with the N55 single turbo engine:

• F20 F21 1 Series M135i
• F22 2 Series M235i
• F87 M2 N55

Installation and support

Direct replacement design using the supplied revised cross member and air shroud. Straightforward swap for the stock cooler, with minor trimming to the plastic cooler support potentially required. For professional fitting, book with MJ Modifications in Warwickshire. Request a quote at info@mjmodifications.co.uk.

Manufacturer

Wagner Tuning

Part number

200001144
